Plating Plant 2ltr 4beaker SS Body (Ultra And Steam Combo Offer)

Product Description

Gold plating is the process in which a ne gold layer is coated over another metal by an electrochemicalreaction. During the electrochemical reaction a DC current gold ions from the gold bath solution is adhered onto the negatively charged piece or article. Gold as itself is ductile and malleable. For enhancing the properties ofthe articles , materials like Silver,Copper and Nickel are introduced and gold plating is done of it to mimic thesame appearance of gold.Plant equipped with 2 beakers, separately powered for heating, with adjusting voltage from the potentiometeron the command panel with electronic protection and 2 magnetic stirrer motor to stirr the solution properly inbeaker.The machine includes S.S. anodes for degreasing or Gold and Oxal anode for Rhodium.The plant is a multi purpose equipment which can replace more machines, saving space and cost. It is bestsuitable for plating any Flash Gold / Rhodium bath

Features:

> Capacity : 2 LitresCCCV

> Constant Current Constant Voltage) Rectier with 12 V - 10 A

> Equipped with 2 borosilicate Glass beakers of 2ltr Capacity

> Digital display for voltage and current

> Voltage adjustment through potentiometer

> Separate magnetic stirrer for both beakers to stirr the solution

>Timer Controller to set process time upto 999 Seconds

> Separate Temperature controlling regulator for adjusting temperature of both beakers

> Provides Steady Voltage that gives desired result in the chemical processes being carried

> Terminals provided with easy access, that can accomodate Pin type, Ring or Fork type connectorssimultaneously as and when required
